Specifications
Load Capacity (kN)
500/600
Load accuracy
Class 0.5
Testing Load Accuracy
≤±0.5%
Testing Load Range
0.4% ~100% of the max. load
Resolution of load
1/500,000FS
Deformation accuracy
≤±0.5% of 0.4%~100% of rated capacity
Position resolution(μm)
0.025
Position accuracy
±0.02mm or 0.5% of displacement (whichever is greater)
Crosshead speed range(mm/min)
0.001-300
Crosshead speed accuracy
±0.5% of set speed (zero or constant load)
Crosshead Travel(mm)
900
Max. Tensile Testing Space(mm)
800
Max. Compression Testing Space(mm)
800
Test width (mm)
700
Compression Platen(mm)
Ф100
Load cell
High-precision USA load cell offers high stiffness, high stability, and high linearity Over-load protection ,lateral loading protection, Bi-direction allows tension and compression test Self-recognition (TEDS) function, Regular self-calibration
Position limit switch
Upper and lower lights
Power Supply
AC220V±10%, 50Hz/60Hz
Overall Dimensions (L*W*H: mm)
1450 x 1140 x 2730
Net Weight(kG)
4000
