Main Parameters
MODEL | ETM104H | ETM204H | ETM504H | ETM105H |
Load Capacity (kN) | 10 | 20 | 50 | 100 |
Load accuracy | Class 0.5 | |||
Testing Load Accuracy | ±0.5% | |||
Testing Load Range(FS) | 0.2%- 100% | |||
Load Resolution | 1/500,000FS | |||
Deformation accuracy | ≤±0.5% of 0.4%~ 100% of rated capacity | |||
Position resolution | 0.025μm | |||
Position accuracy | ±0.02mm or 0.5% of displacement (whichever is greater) | |||
Crosshead speed range | 0.001- 1000 | 0.001-500 | ||
Crosshead speed accuracy | ±0.5% of set speed (zero or constant load) | |||
Crosshead Travel(mm) | 1000 | 1100 | ||
Max. Tensile Testing Space(mm) | 800 | 800 | 800 | 700 |
Max. Compression Testing Space(mm) | 800 | 800 | 800 | 700 |
Test width (mm) | 450 | 450 | 450 | 550 |
Compression Platen(mm) | Ф98 | Ф98 | Ф98 | Ф98 |
Load cell | High-precision USA load cell offers high stiffness, high stability, and high linearity Over-load protection ,lateral loading protection, Bi-direction allows tension and compression test Self-recognition (TEDS) function, Regular self-calibration | |||
Position limit switch | Upper and lower lights | |||
Power Supply | AC220V± 10%, 50Hz/60Hz | |||
Overall Dimensions (L*W*H: mm) | 930x600x 1897 | 930x600x 1897 | 1030x600x2030 |
