KASON CET-40 Corrosion Erosion Wear Tester
Corrosion Erosion Wear Tester is mainly used to measure the resistance of metallic and non-metallic materials to high-speed scouring and corrosion in environments such as acid solutions, alkaline solutions and mortar. It is an essential simulation evaluation tester for material-related industries including exploration, drilling materials, pipeline transportation and valve manufacturing.
Specification
|
Item |
Specification |
|
Maximum Impact Velocity |
40m/s |
|
Impact Linear Speed Control Accuracy |
±5% |
|
Spindle Stepless Speed Range |
0 ～ 1400r/min |
|
Spindle Speed Error |
±5r/min |
|
Revolution Count |
0 ～ 99999999 cycles |
|
Test Duration |
999 hours |
|
Temperature Measurement Range |
0 ～ 500℃ |
|
Sand Content |
≤30% |
|
Specimen Dimension |
Φ15mm × 20mm |
|
Test Medium |
Oil, water (seawater), slurry, etc. |
|
Maximum Output Power of Main Motor |
7.5kW |
|
Outer Diameter of Impeller |
300mm |
