Application:
Can be used to determine un-quenched steel.,Cast iron.,Non-ferrous metal and the soft texture of bearingmetal materials brinell hardness value.
Main Technical Parameter
Brinell hardness scale:
HBW2.5/62.5、HBW2.5/187.5、HBW5/125、HBW5/750、HBW10/100、HBW10/1500、HBW10/3000、HBW10/250、HBW10/500、HBW10/1000
Test force:62.5kgf(612.9N),100kgf(980.7N),125kgf(1226N),187.5kgf(1839N)、250kgf(2452N)、500kgf(4903N)、750kgf(7355N)、1000kgf(8907N)、1500kgf(14710N)、3000kgf(29420N)
Max. Height of sample:280mm
Min. Measurement unit:0.01mm
Dwell time:6-99s
Hardness testing range:8-650HBW, 8-450HBS
Distance from indenter center to the wall:150mm
Hardness reading:comparison with hardness form
Voltage:AC220+5%,50~60Hz
Tungsten carbide ball penetrator: Dia. 2.5, 5, 10mm
