KASON-PB100W Automatic plastic ball hardness tester
Product introduction
The digital pencil hardness tester is specially used to test the hardness of pencil leads of various pencils and implements the standard "GB/T 26704-2011 Pencils". This product is widely used in the domestic pencil manufacturing industry.
Technical Parameters
|
model Name |
KASON-PB100W |
|
Implementation standards |
GB/T 26704-2011 pencil |
|
Test force（N） |
0.245、0.49、0.98、1.96、2.94、4.98 |
|
Minimum test unit |
0.01µm |
|
Hardness test range (HK) |
40-700 |
|
Test force application method |
Automatic (loading, holding, unloading) |
|
Indenter and lens conversion |
Automatic |
|
Test microscope magnification |
100X (observation, testing) 200X (testing) |
|
Test force holding time |
1~99s, 10s recommended |
|
X-Y test bench |
Size: 100*100mm Maximum movement: 25*25mm |
|
data output |
LCD display readout, built-in printer |
|
Effective height of workpiece |
100mm |
|
Distance from center of indenter to outer wall |
130mm |
|
power supply |
AC220V+5%，50-60Hz |
|
Dimensions |
540*260*650mm |
|
Host weight |
About 50Kg |
