KASON HDT-A Microcomputer Servo Fatigue Testing Machine
Application
Mainly used to do the dynamic and static mechanical fatigue test for materials and parts . The machine could also complete the fatigue test of other structural parts with different fixture. The machine also can be used for materials or structural parts, auto parts and other static mechanical performance test. It is a popular machine for the university, research institutes, enterprises and other experimental equipment to test.Main parameters
|
Model |
KASON- HDT504A |
KASON- HDT105A |
KASON-HDT255A |
KASON- HDT505A |
KASON-HDT106A |
KASON-HDT20A |
|
Maximum dynamic force (kN) |
±50 |
±100 |
±250 |
±500 |
±1000 |
±2000 |
|
Maximum static force (kN) |
50 |
100 |
250 |
500 |
1000 |
2000 |
|
Load range |
2%-100%FS |
|||||
|
Testing machine accuracy |
Static indication accuracy: ±0.5% Dynamic loading accuracy: ±1% |
|||||
|
Actuator dynamic stroke(mm) |
150 |
|||||
|
Displacement measuring range (mm) |
0～150(±75) |
|||||
|
Displacement measurement resolution(mm) |
0.001 |
|||||
|
Deformation indication relative error |
±0.5% |
|||||
|
Sine wave test Frequency (Hz) |
Standard: 0.01～30; Optional: 0.01～50; 0.01～100(Static pressure support cylinder) |
|||||
|
Test space (mm) |
1500 |
|||||
|
Test width（mm） |
720 |
|||||
|
Main frame stiffness |
3×108 |
|||||
|
Coaxiality of hydraulic fixture |
5% |
|||||
|
Power supply |
AC 380V± 10%, 50Hz |
|||||
