METPRESS-3AS Metallographic automatic hot mounting machine
1、Application
The METPRESS-3AS mounting machine is used to mount metallographic and petrographic samples that are tiny, difficult to hold or irregular before grinding and polishing.
2、Technical Parameters
|
Model |
METPRESS-3AS |
|
The Sample Diameter |
30mm(φ25mm, φ40mm, φ50mm customized) |
|
Heater |
220V 1650W*2 |
|
Heating temperature range |
35~200 |
|
Keeping time range |
1-99min |
|
Cooling time range |
0~60min |
|
Dimension |
677*490*545mm |
|
Package Size |
777*615*706mm |
|
Net Weight |
94.2kg |
|
Gross Weight |
110.25kg |
