Brick Tile Hydraulic Cement Compression Testing Machine

Brick Tile Hydraulic Cement Compression Testing Machine
Brick Tile Hydraulic Cement Compression Testing Machine
Brick Tile Hydraulic Cement Compression Testing Machine



Application

This series compression testing machine is mainly designed for compression test of building material items, such as concrete cube, concrete blocks, cement specimen, and bricks etc, also used for compression performance test of rubber pad and top forge test of metal. With new design idea and advanced technology, this series have more advantages in appearance, operation & applications. It is the ideal test equipment for quality control at industry & mineral enterprises, education in high schools, and technology researches at scientific institutes.

Main Specifications

Model

YAW-300C


Max compression test force(kN)

300kN compression /10kN Bending

Test Accuracy

±1%

Test measurement range

4%-100%FS

Control way

Computer control auto loading progress

Test space adjustment method

Block adjustment test space

Rate of loading

2.4KN/S(compression resistance ) 50N/S (bending resistance)

Oil cylinder piston diameter and stroke

50 mm

Distance between compression plates

180mm

Upper and lower compression plates size

Φ108mm /Φ60mm

Size

860mm×430mm×1100mm

Power supply

380V, 50HZ, 0.75KW
