Application fields:
Heat treatment, carbide, quench hardened layer, the surface coating layer, steel, non-ferrous metal and small and thin shape parts, etc.
Technical Parameters :
Model
HTV-5/10/30/50A
HTV-5/10/30/50AD
HTV-5/10/30/50AT
7HTV-5/10/30/50AT
Display model
Small LCD digital display
Big LCD digital display
touch screen
Big touch screen
Turret Type
Automatic Direct display
Test force
5/5Z/5ZTH
10/10Z/10ZTH
30/30Z/30ZTH
50/50Z/50ZTH
0.3Kgf(2.91N),0.5Kgf(4.9N),1Kgf(9.8N),2Kgf(19.6N), 3Kgf(29.4N), 5Kgf(49.0N)
0.3Kgf(2.91N), 0.5Kgf(4.9N), 1Kgf(9.8N),2Kgf(19.6N), 3Kgf(29.4N), 5Kgf(49.0N),10Kgf(98.0N)
1.0 Kgf(9.8N)、2.0Kgf(19.6N)、2.5Kgf(24.5N)、3.0Kgf(29.4N)、5.0Kgf(49.0N)、10.0Kgf(98.0N),20.0Kgf(196N)、30.0Kgf(294N)、
1.0 Kgf(9.8N)、2.0Kgf(19.6N)、2.5Kgf(24.5N)、3.0Kgf(29.4N)、5.0Kgf(49.0N)、10.0Kgf(98.0N)、20.0Kgf(196N)、30.0Kgf(294N)、40.0Kgf(392.0N)、50.0Kgf(490N)
Loading and unloading mode
Automatic
Dwell Time
Adjustable 0 to 60 seconds
Conversion Scale
Rockwell, Brinell
Hardness measuring range
8~2900HV
Amplification of Test Microscope
200X,400X
100X,200X
Max. Height of Specimen
160mm
Depth at center line
135mm
RS232,Built-in print, data statistics
NO
YES
Power Supply
AC220V±5%,50~60Hz
