KASON-TP5 Computer controlled spring fatigue testing machine （20HZ）

1.Introduction
This series of testing machines is a specialized testing equipment designed and manufactured strictly in accordance with national standards for mechanical testing of fatigue life. It is widely used for testing the tensile and compressive fatigue performance of various materials such as springs, fiber materials, plastics, etc. It can measure the fatigue performance of specimens under a certain amount of deformation. The entire cycle testing process of material samples is automatically completed by microcomputer control, which can detect performance parameters such as force attenuation of the samples and print test reports. Users can adjust the testing program according to their actual needs during use, which is extremely convenient to operate. It can replace imported products of the same type and is the preferred choice for manufacturers and users of new materials, building materials, and other materials.
2. Specification
1)Maximum test force: 5000N
2)Test force resolution: 0.1N (full range resolution remains unchanged)
3)Accurate measurement range of force value: 2% FS-100% FS
4)Dynamic fluctuation of test force indication: 1% FS;
5)Test bench width: approximately 330mm
6)Test height: approximately 450mm (can be customized according to customer requirements)
7)Displacement resolution: 0.01mm
8)Amplitude: ± 50mm (adjustable)
9) Frequency: 0.1-20Hz (adjustable)
10)Test waveform: sine wave
11)Machine size: approximately 590 * 330 * 1300mm
12) Display: Computer screen display
