DP Microcomputer Control Electronic Fatigue Testing Machine
Application
Mainly used to do the dynamic and static mechanical fatigue test for materials and parts . The machine could also complete the fatigue test of other structural parts with different fixture. The machine also can be used for materials or structural parts, auto parts and other static mechanical performance test. It is a popular machine for the university, research institutes, enterprises and other experimental equipment to test.
Main parameters
|
Model |
Kason-DP2 |
Kason-DP5 |
Kason-DP10 |
Kason-DP20 |
|
Max testing force |
±2000N |
±5000N |
±10000N |
±20000N |
|
Load frame |
Two-column platform type, cross beam electric adjustment |
|||
|
Effective column width |
555 |
555 |
600 |
600 |
|
Test space
|
550 |
550 |
750 |
750 |
|
Test force measuring range |
Dynamic2%～100%FS |
|||
|
Force accuracy and fluctuation |
1% better than indicated value; amplitude fluctuation is not greater than ± 1% F.S |
|||
|
Load display resolution
|
1/50000 |
|||
|
Test force indication accuracy |
Dynamic ± 1%; static 0.5% |
|||
|
Displacement measurement range |
150mm(±75mm) |
|||
|
Displacement resolution |
0.001mmm |
|||
|
Displacement indication accuracy |
Indication accuracy from 1%, within ± 0.5% FS |
|||
|
Deformation |
Indication accuracy: 2%~ ± 0.5% |
|||
|
Frequency rang
|
standard machine 0.1-10HZ,can Optional20HZ,30HZ,50HZ
|
|||
|
Accessories
|
Standard :Compression, bend, shear etc.(option) |
|||
|
Test waveform: |
sine wave, square wave, triangle wave, ramp wave, etc.
|
|||
