Standard:
ASTM, ISO, DIN, GB and other international standards.
Main Technical Parameters:
Model | KASON WDS-01,02,03,05,1,2,3,5 |
Structure | Single column double spaces |
Max. Load(kN) | 0.1, 0.2, 0.3, 0.5, 1, 2, 3 ,5 |
Material | All aluminum alloy surface spray painting shell |
Load accuracy | ISO 7500Class1 |
Load range | 2%~100%F·S |
Load resolution | 1/ 50000 |
Resolution of displacement | 0.01mm |
Test speed(mm/min) | 1-500stepless arbitrary setting |
Speed accuracy | within ±1% set speed |
E-Tensile space(mm) | 600(can be customized) |
E-Compression space(mm) | 600(can be customized) |
D-Test width(mm) | 100 |
F-Beam travel distance(mm) | 772 |
H-Workbench thickness(mm) | 26 |
G-Base height(mm) | 158 |
Power supply | AC220V±10%,50Hz/60Hz(can be customized) |
