1. ApplicationThe Testing Machine Tests the mechanical properties of cement, mortar, brick, concrete and other building materialswith servo motor acceleration and deceleration control technology, showing the load value, loading speed and loading curve. The test data is automatically processed, stored, and printed.
2. Standards:
ISO 679, DIN 1164: Cement -- Test methods -- Determination of strength;
ASTM C348: Standard Test Method for Flexural Strength of HydraulicCement Mortars;
ASTM C349: Standard Test Method for Compressive Strength of Hydraulic-Cement Mortars (Using Portions of Prisms Broken in Flexure);
ASTM C109 / C109M: Standard Test Method for Compressive Strength of Hydraulic Cement Mortars;
BS EN 196-1: Methods of Testing cement. Determination of strength;
ASTM C880 / C880M: Standard Test Method for Flexural Strength of Dimension Stone;
ASTM C170 / C170M: Standard Test Method for Compressive Strength of Dimension Stone;
EN12390-5 BS 1881:118, ASTM C78, C293, ASHTO T97: Testing hardened concrete. Flexural strength of test specimens.
3. Features and Function:
3.1 Closed-loop control system constantly monitors the test in progress and regulates the testing rate to maintain prescribed conditions.
3.2 Compact design requires less room in the lab and oil free drive system not only keep the lab clean but also low noisy.
3.3 Stable and reliable high intensity structure load frame with extended tabletop provides extra area for placement of additional jigs.
3.4 Real time display software ensures the accurate track of testing process.
3.5 Pre-built test methods for cement mortar, concrete prism, dimension stone and user configurable test methods are available.
3.6 Overload and over travel protection available for secure operator and machine.
3.7 Custom report template available.
3.8 Easily expand test solutions at a later date with hardware and software options.
4. Selling points:
1. High Precision & Stable Loading
Adopts high-precision pressure sensor and closed-loop control, ensuring test accuracy complies with ISO 679, EN 196-1, GB/T 17671.
Stable and uniform loading rate, no impact, no overshoot, guaranteeing reliable and repeatable test data.
2. Dual Functions: Compression + Flexural
Integrated structure for compression test and flexural test in one machine, high efficiency and cost-effective.
Standard accessories include Compression Platen, flexural fixture, supporting rollers, suitable for cement, mortar, concrete and brick samples.
3. Automatic Control & Intelligent Operation
Microcomputer or touch-screen control, automatic constant loading rate, automatic stop when specimen breaks.
Automatically calculates strength values, displays load-displacement curve, and supports data storage, printing and export.
4. Strong Rigidity & Long Service Life
High-strength steel frame with good rigidity, small deformation under maximum load.
High-quality hydraulic components / electric servo system, low noise, stable performance and low maintenance.
5. Easy Operation & Safe Design
Simple operation interface, easy calibration and parameter setting.
Equipped with over-load protection, emergency stop and safety guard, ensuring operator safety.
6. Wide Application
Specially designed for cement, mortar, concrete, lightweight bricks, refractory materials and other building materials.
Ideal for quality control in laboratories, construction sites, cement factories and inspection institutions.
