Application:
The metal wire torsion testing machine is suitable for measuring the ability of metal wire with adiameter (orcharacteristic size) of 0.1-6.0mm to withstand plastic deformation in one-way or two-way torsionandtodisplay the surface and internal defects of the wire. This machine is mainly used for the analysis of the mechanical properties of metal wires in themechanicslaboratories of colleges, universities, scientific research departments, and industrial and miningenterprises.It is also widely used for online inspection of production units; the main industries include high-speedsteel lines, prestressed steel wire plants, and quality Supervision, scientific research institutes, highwaytransportation, construction industry, steel wire ropes, wires and cables, copper and copper alloywiresforelectrified railways, copper contact wires and other production and use departments.
Technical parameter:
Loading method | Auto load |
Display method | LCD screen display |
metal wire diameter | 0.1≤d(D)<6.0 |
Space between two fixtures | 500mm |
Jaw clamping range | 1-12mm |
Clamping block hardness | >55HRC |
Torsion speed | 30、60、90、120r/min(could be customized) |
Speed error | <±5% |
Minimum reading value of turns | 0.1 |
Size (L * W * H) | 1250×430×600mm |
Net weight | 140kg |
Power | AC 220V 50Hz |
Noise | <50 dB(A) |
