1,Overview:
This test instrument is mainly used for electronic and electrical components or parts under fault or overload conditions, which may reach excessively high temperatures or ignite parts near them. The glow-wire test simulates the thermal stress caused by a heat source or ignition source such as a hot element or an overload resistance over a short period of time, the simulation technology is used to assess fire hazard. It is suitable for electrical and electronic products, components, household electrical appliances components with plastic non-metallic insulation materials and parts, such as: switch shell, relay sockets, etc.
2, Standards compliant:
GB19083-2010, YY0469-2011, GB / T12903-2008, GB2626-2019 "Respiratory protective equipment self-priming filter anti-particulate respirator" 6.15 Flammability
3,Specification:
item |
value |
Model Number |
KASON-MTB505 |
Power |
Electronic |
Product Name |
Flammability Testing Equipment |
Material |
Stainless Steel |
Flame Temperature Measurement |
100 ℃ ± 2 ℃ To 700 ℃ ± 3 ℃ |
Certification |
CE |
Burner Needle Diameter |
Diameter 0.5 ± 0.1mm |
Test Chamber |
0.5 Cubic Meters |
Usage |
Needle Flame Test |
Power |
Electronic |
