Overviewer:
These machines offer force, displacement or deformation closed loop testing. The load frames are rigid constructed, providing superior axial and lateral stiffness.
Main specifications:
Load capacity: | 100kN for tension, 10kN for crush test |
Accuracy class: | ±1% |
Measuring range: | 1%-100% |
Crush platen: | 100mm×100mm,hardness:HB240~280 |
loading speed: | 0.2~300mm/min |
Deformation measuring accuracy: | ±0.5% |
Displacement measuring accuracy: | ±0.3% |
Elongation measurement: |
1. gauge length:1000mm 2. Measuring resolution is better than 10μm 3. Accuracy is better than ±0.5%. |
Crosshead travel: | 800~1100mm |
